Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
RF Type General Purpose
Frequency 2.3GHz to 2.7GHz
Number of Mixers 1
Gain 8.5dB
Noise Figure 10.5dB
Secondary Attributes Down Converter
Operating Supply Current 160mA
Supply Voltage - Operating 3 V to 5 V
Case / Package 44-VFQFPN (7x7)
Win Source Part Number 1104065-STW82103BTR
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian STW82103BTR CAD Model

Description

The STW82103BTR by STMicroelectronics is a cutting-edge RF synthesizer designed to deliver high performance and versatility in a wide range of applications. This integrated circuit is part of STMicroelectronics' extensive portfolio of RF products that cater to the demanding requirements of wireless communication systems.

Key Features

  • Frequency Range: The STW82103BTR operates over a broad frequency range, making it suitable for various applications, including but not limited to, wireless infrastructure, test equipment, and satellite communications.
  • Low Phase Noise: One of the standout features of this device is its low phase noise, which ensures a clean signal and minimizes interference in communication systems.
  • Integrated Voltage Controlled Oscillators (VCOs): The inclusion of integrated VCOs simplifies the design process and reduces the need for external components, thereby saving space and cost.
  • Programmable Dividers: With programmable dividers, users can easily adjust the frequency to meet the specific requirements of their application.
  • Serial Interface: The STW82103BTR comes with a serial interface for programming, which enables easy control and configuration of the device.

Applications

Thanks to its versatile features, the STW82103BTR can be used in a variety of applications, including:

  • Wireless infrastructure (e.g., base stations for cellular networks)
  • Broadband wireless access systems
  • Satellite communication systems
  • Test and measurement equipment

Product Specifications

The STW82103BTR is available in a compact QFN package that is both space-efficient and conducive to high-density PCB layouts. It is designed for operation over the industrial temperature range and is characterized by a balance of performance and power efficiency, making it an ideal choice for portable and battery-powered applications where power consumption is a critical factor.

Conclusion

The STW82103BTR RF synthesizer from STMicroelectronics represents a blend of performance, integration, and efficiency. Its comprehensive feature set and broad application scope make it a valuable component for designers looking to optimize their RF systems. As with all STMicroelectronics products, this device is backed by the company's commitment to quality and reliability.
