Products specifications Report Issue?

Manufacturer STMicroelectronics
Standard Package 30
Category Discrete Semiconductor Products
Family Transistors (BJT) - Single
Packaging Tube
Transistor Type PNP
Current - Collector (Ic) (Max) 15A
Voltage - Collector Emitter Breakdown (Max) 60V
Vce Saturation (Max) @ Ib Ic 3V @ 3.3A 10A
Current - Collector Cutoff (Max) 700µA
DC Current Gain (hFE) (Min) @ Ic Vce 20 @ 4A 4V
Power - Max 90W
Mounting Style Through Hole
Package TO-247-3
Manufacturer Device Package TO-247-3
Catalog PNP Transistors
Win Source Part Number 092167-TIP2955
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TIP2955 CAD Model

Description

Product Overview: TIP2955 Power Transistor by STMicroelectronics

The TIP2955 is a silicon Epitaxial-Base Planar PNP transistor mounted in a TO-247 plastic package. It is designed by STMicroelectronics, a global semiconductor leader known for its state-of-the-art electronic components. The TIP2955 is intended for use in power linear and switching applications, offering a robust and reliable solution for a wide range of electronic circuits.

Key Features

  • High Current Performance: With a collector current capability of up to -15 A, the TIP2955 is suitable for high-power applications.
  • High Voltage Tolerance: The transistor can handle up to -60 V across the collector-emitter junction, making it ideal for circuits that require a high breakdown voltage.
  • Low Saturation Voltage: This feature minimizes voltage drops and improves efficiency, which is particularly beneficial in power amplification and switching applications.
  • Complementary NPN Type: The TIP3055 is the complementary NPN transistor, allowing for the creation of complementary or push-pull configurations.

Applications

The versatile nature of the TIP2955 allows it to be used in a variety of applications, such as:

  • Power regulators and converters
  • Audio power amplifiers
  • Switching circuits
  • Driver stages in hi-fi amplifiers and television circuits

Reliability and Quality

STMicroelectronics is committed to delivering high-quality products. The TIP2955 is no exception, with its robust construction ensuring long-term reliability. The device is also characterized by its low thermal resistance, which contributes to better stability and longevity under various operating conditions.

Environmental and Safety Compliance

In line with modern environmental standards, the TIP2955 adheres to RoHS (Restriction of Hazardous Substances) and is free from environmentally damaging substances. This commitment to environmental safety ensures that the TIP2955 is suitable for use in a wide range of consumer and industrial products while being mindful of ecological impact.
