Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 1.3 V/μs
Gain Bandwidth Product (GBP) 1.4MHz
Current - Input Bias 1pA
Voltage - Input Offset 10mV
Operating Supply Current 400μA
Channel Output Current 75mA
Supply Voltage - Operating 2.7 V to 16 V, ±1.35 V to 8 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 083837-TS912ID
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TS912ID CAD Model

Description

STMicroelectronics Product TS912ID Overview

The TS912ID is a high-performance operational amplifier from STMicroelectronics, designed to meet the requirements of a wide range of electronic applications. This device is a rail-to-rail input/output dual operational amplifier which operates on a power supply ranging from 2.7V to 16V. The TS912ID is particularly suited for portable and battery-powered applications due to its low-power consumption and its ability to operate at low voltages.

Key Features

  • Rail-to-Rail Input/Output: The TS912ID can handle input and output signals that include the full range of power supply levels, improving signal range and quality.
  • Low Power Consumption: With a typical quiescent current of just 200 µA, this op-amp is an excellent choice for energy-sensitive applications.
  • Wide Supply Voltage Range: The device can be powered with a supply voltage from 2.7V to 16V, offering flexibility in various circuit designs.
  • High Output Current: Capable of delivering an output current up to 40 mA, the TS912ID can drive heavier loads when necessary.
  • Stable Performance: The operational amplifier maintains stability for capacitive loads up to 500 pF, which is essential for consistent and reliable operation.

Applications

The TS912ID is versatile and can be used in a variety of applications. Some of its common uses include:

  • Portable devices
  • Battery-powered applications
  • Analog signal conditioning
  • Active filtering
  • Medical instrumentation
  • Automotive electronics

Package and Quality

The TS912ID is available in an SO-8 package, which is compact and suitable for space-constrained applications. STMicroelectronics ensures that this product meets high-quality standards, with rigorous testing and validation processes in place to guarantee performance and reliability.

In summary, the TS912ID operational amplifier from STMicroelectronics is an excellent choice for designers looking for a low-power, high-performance solution for their electronic circuits. Its rail-to-rail capability, wide supply voltage range, and stable performance make it a versatile component for a multitude of applications.
