Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 1 V/μs
Gain Bandwidth Product (GBP) 3MHz
Current - Input Bias 35nA
Voltage - Input Offset 6mV
Operating Supply Current 950μA
Channel Output Current 10mA
Supply Voltage - Operating 2.7 V to 12 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SO
Win Source Part Number 035250-TS954IDT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TS954IDT CAD Model

Description

The TS954IDT is a cutting-edge operational amplifier (op-amp) designed by STMicroelectronics, a global semiconductor leader renowned for its innovative and reliable products. This op-amp is part of the company's extensive range of low-power, high-precision amplifiers that are ideal for a wide array of applications.

One of the key features of the TS954IDT is its low-power consumption, which makes it suitable for battery-powered devices and other applications where power efficiency is crucial. The device operates on a supply voltage range from 2.7V to 16V, providing designers with flexibility in various power environments.

The TS954IDT boasts a rail-to-rail input and output, which allows for a wider dynamic range within the given supply voltage. This feature is particularly beneficial for applications that require the full use of the available voltage span, such as data acquisition systems and portable electronics.

With an extended temperature range from -40°C to +125°C, the TS954IDT is robust and reliable, ensuring stable performance in even the most demanding conditions. This makes the op-amp an excellent choice for automotive and industrial applications where temperature extremes are commonplace.

The device also features low input offset voltage and low noise, which are critical specifications for precision applications. The low input bias current further enhances the accuracy of the op-amp, making it suitable for sensor interfaces and control systems.

The TS954IDT comes in a small, surface-mount SO-14 package, which is beneficial for space-constrained applications. Its small footprint and the option for tight packing of components on a PCB make it a go-to choice for compact electronic designs.

In summary, the TS954IDT from STMicroelectronics is a versatile, low-power operational amplifier that offers high precision, rail-to-rail input and output, and robust performance in a wide temperature range. Its small package and power efficiency make it an ideal choice for a broad spectrum of applications, from automotive to consumer electronics.
