Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type with Voltage Reference
Number of Elements 2
Supply Voltage - Operating 2 V to 36 V, ±1 V to 18 V
Voltage - Input Offset (Max) 5mV @ 5V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 20mA @ 5V
Current - Quiescent (Max) 2.5mA
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 113667-TSM109AIDT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TSM109AIDT CAD Model

Description

The TSM109AIDT is a versatile and precision integrated circuit from STMicroelectronics, designed to cater to a wide array of applications requiring dual operational amplifiers (op-amps) and a voltage reference. This compact, multifunctional component is an ideal choice for power supply management and control systems, where space and accuracy are critical considerations.

Key Features

  • Dual Operational Amplifiers: The TSM109AIDT includes two independent op-amps with low offset voltage and high gain bandwidth product, ensuring accurate amplification and signal conditioning in analog circuits.
  • Precision Voltage Reference: A stable and precise 2.5V voltage reference is integrated into the device, providing a reliable benchmark for analog-to-digital conversions, voltage monitoring, and control loop applications.
  • Low Power Consumption: Designed for efficiency, the device features a low supply current, making it suitable for battery-powered and energy-sensitive applications.
  • Wide Operating Voltage Range: The TSM109AIDT operates over a broad supply voltage range, accommodating various system requirements and ensuring compatibility with both digital and analog circuits.
  • Robust Design: The device is characterized by its robustness, offering protection against short-circuit and thermal overload, which enhances the reliability and longevity of the applications it is used in.

Applications

The TSM109AIDT is adept at serving in diverse roles across numerous sectors. Its precision and stability make it suitable for:

  • Power supply control and monitoring
  • Battery chargers and management systems
  • Automotive and industrial control systems
  • Sensor signal conditioning
  • Portable and wearable electronics

Package and Quality Assurance

The TSM109AIDT is offered in a compact SO-8 package, which is conducive to space-constrained designs without compromising performance. STMicroelectronics ensures high-quality standards, with the device being subjected to rigorous testing and validation procedures. This ensures that each unit meets the stringent requirements necessary for critical and high-reliability applications.

Whether you're developing power management systems, precision instrumentation, or portable devices, the TSM109AIDT from STMicroelectronics provides the functionality and reliability needed to enhance your project's performance.
