Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 0.6 V/μs
Gain Bandwidth Product (GBP) 1.4MHz
Current - Input Bias 70nA
Voltage - Input Offset 200μV
Operating Supply Current 500μA
Channel Output Current 80mA
Supply Voltage - Operating 2.5 V to 6 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 1114800-TSV321RILT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TSV321RILT CAD Model

Description

The TSV321RILT from STMicroelectronics is a high-performance, single operational amplifier (op-amp) designed to offer a blend of features that make it ideal for a wide range of applications. This device is part of STMicroelectronics' TSV321 series, known for its low-voltage operation and low power consumption. With its Rail-to-Rail input and output capability, the TSV321RILT provides excellent linearity and can operate at power supplies ranging from 2.7V to 5.5V, making it versatile for both single and dual power supply operations.

The TSV321RILT boasts a low input offset voltage and high-speed performance with a gain bandwidth product of 1.4MHz. This feature ensures the op-amp can handle a broad spectrum of signals without significant distortion, making it suitable for sensor signal conditioning, battery-powered applications, and active filtering. Its low-power consumption, typically just 29 µA, is particularly beneficial for portable and battery-operated devices where power efficiency is crucial.

With an extended temperature range from -40°C to +125°C, the TSV321RILT is designed to perform reliably in extreme conditions, which is essential for automotive and industrial applications. The device is available in a tiny 5-pin SOT23-5 package, which is perfect for space-constrained applications.

Furthermore, the TSV321RILT offers protection features such as input and output short-circuit protection, which safeguard the device against fault conditions. Its low input bias current of 1pA typ. makes it an excellent choice for applications requiring precision and low steady-state error.

In summary, the TSV321RILT operational amplifier from STMicroelectronics is a high-quality, general-purpose op-amp that combines low power consumption with high-speed performance, Rail-to-Rail input and output, and robust protection features. Whether it's for consumer electronics, automotive, or industrial applications, the TSV321RILT is engineered to provide reliable and efficient operation, making it a go-to solution for designers looking for a versatile and compact amplifier solution.
