Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 0.19 V/μs
Gain Bandwidth Product (GBP) 400kHz
Current - Input Bias 70pA
Voltage - Input Offset 1μV
Operating Supply Current 31μA
Channel Output Current 18mA
Supply Voltage - Operating 1.8 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-TSSOP
Win Source Part Number 1114844-TSZ124IPT
Family Name TSZ124
Introduction Date October 29, 2013
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TSZ124IPT CAD Model

Description

Introducing the TSZ124IPT Precision Operational Amplifier

The TSZ124IPT is a cutting-edge precision operational amplifier (op-amp) from STMicroelectronics, designed to meet the needs of a wide range of applications that require high accuracy and stability. This quad op-amp is part of STMicroelectronics' renowned TSZ family, known for its zero-drift technology that ensures ultra-low input offset voltage and virtually eliminates the drift over time and temperature variations.

Key Features

  • Ultra-Precise Performance: With an input offset voltage as low as 5 µV at 25°C and a temperature drift typically around 30 nV/°C, the TSZ124IPT offers exceptional precision for the most demanding applications.
  • Low Power Consumption: Despite its high precision, the TSZ124IPT is designed for efficiency, with a low supply current of just 40 µA per amplifier, making it suitable for battery-powered devices and energy-sensitive applications.
  • Wide Operating Voltage Range: The device can operate across a wide supply voltage range from 2.2 V to 5.5 V, providing flexibility in various operating conditions and system designs.
  • Extended Temperature Range: The TSZ124IPT is designed to perform reliably over an extended temperature range from -40°C to +125°C, ensuring consistent performance in harsh environments.
  • Robust Design: It features an EMI filtering capability, which enhances the op-amp's robustness against electromagnetic interference, making it ideal for industrial and automotive applications.

Applications

The TSZ124IPT's precision characteristics make it an excellent choice for a variety of applications, including:

  • High-precision sensors and instrumentation
  • Automotive control systems
  • Medical equipment
  • Portable and battery-powered devices
  • Analog-to-digital converter (ADC) buffer

Package and Quality Assurance

The TSZ124IPT is available in a compact TSSOP-14 package, which is ideal for space-constrained applications. Additionally, STMicroelectronics' commitment to quality ensures that each op-amp meets the highest standards of performance and reliability.

With its exceptional precision, low power consumption, and robust design, the TSZ124IPT from STMicroelectronics stands out as an ideal solution for applications requiring the utmost in accuracy and stability.
