The VN5E010MHTR-E from STMicroelectronics is a high-efficiency, automotive-grade Power MOSFET, designed to deliver outstanding performance in a wide range of automotive applications. This robust component is part of ST's VIPower M0-5 Enhanced series and is specifically engineered to meet the stringent requirements of the automotive industry, including load dump protection and compliance with ISO 7637-2 and ISO 16750-2 standards.

Key Features

• High-Side Switch: The VN5E010MHTR-E operates as a single channel high-side driver, allowing for direct control of the load.
• Current Rating: With a continuous current rating of 25A, this Power MOSFET can handle significant power loads, making it ideal for automotive applications.
• Low On-Resistance: The low on-resistance (R<sub>DS(on)) of this device ensures efficient operation with minimal power loss, contributing to the overall efficiency of the system.
• Protection Features: It includes over-temperature protection, overload protection, and active clamp to safeguard the device and the system it is a part of.
• Diagnostic Functions: Integrated diagnostic functions provide feedback on the status of the device, enabling system monitoring and fault detection.
• Temperature Range: The VN5E010MHTR-E is designed to operate over a wide temperature range, from -40°C to 150°C, accommodating the thermal extremes of automotive environments.
• Package: Housed in a compact and rugged HSSOP24 package, it is designed for space-constrained applications while providing excellent thermal performance.

Applications

The VN5E010MHTR-E is suitable for a variety of automotive applications, including but not limited to:

• Automotive lighting systems
• Engine control units
• Body control modules
• Intelligent power distribution

Overall, the VN5E010MHTR-E is an exceptional choice for automotive manufacturers and suppliers looking for a reliable, high-performance power switch with advanced protection and diagnostic features.
