Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 51 Weeks
Manufacturer STMicroelectronics
Series Automotive, AEC-Q100, VIPOWER™
Package Reel - TR
Operating Temperature Range -40°C ~ 150°C (TJ)
Mounting Surface Mount
Package 16-PowerLFSOP (0.154", 3.90mm Width)
Case / Package PowerSSO-16
Family Name VND7E050
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 497-19574-1, 497-19574-2, 497-19574-6
Quantity per package 2500
Popularity High
Supply and Demand Status Balance
Win Source Part Number 938728-VND7E050AJTR
Ultra Librarian 3D Model Ultra Librarian VND7E050AJTR CAD Model

Description

Introducing the VND7E050AJTR from STMicroelectronics

The VND7E050AJTR is a state-of-the-art automotive-grade double channel high-side driver manufactured by STMicroelectronics, a leader in the semiconductor industry. This product is designed to deliver a reliable and efficient performance for driving resistive, inductive, and capacitive loads. With its robust feature set, the VND7E050AJTR is an ideal solution for a wide range of automotive applications, including but not limited to, headlights, heaters, and car audio systems.

Key Features

  • Current Control: Each channel of the VND7E050AJTR can handle high currents, with an extended range of diagnostic capabilities.
  • Advanced Protection: The device includes over-temperature protection, overload protection, and short-circuit protection. These features ensure the safety and longevity of the device under harsh operating conditions.
  • High Integration: The high-side driver integrates a range of functions that minimize external component count, simplifying design and reducing overall system cost.
  • MultiSense Diagnostics: The VND7E050AJTR features precise and advanced diagnostics to monitor load conditions, including current sensing, open load detection, and over-temperature warning.

Technical Specifications

The device operates with a supply voltage range from 5.5 V to 36 V, making it suitable for 12V, 24V automotive battery systems. It has a very low standby current consumption, which is critical for power-sensitive applications. The VND7E050AJTR also boasts a high-side switch embedded with a charge pump, ensuring gate drive for the MOSFETs even at low supply voltages.

Applications

The VND7E050AJTR is versatile and can be used in a variety of automotive environments. Its robust design and comprehensive diagnostic features make it particularly well-suited for:

  • Automotive exterior and interior lighting
  • Engine and transmission control units
  • Body control modules
  • Automotive infotainment systems

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The VND7E050AJTR is no exception and is designed to meet the stringent requirements of the automotive industry. It comes in a compact, surface-mount package which is RoHS compliant and is qualified under AEC-Q100, ensuring reliability for automotive applications.

With the VND7E050AJTR, STMicroelectronics continues to provide innovative, robust, and high-performance solutions for the automotive market.
