Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Bulk
Status Active
Triac Type Logic - Sensitive Gate
Voltage - Off State 600V
Current - On State (It (RMS)) (Max) 4A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 20A, 21A
Current - Gate Trigger (Igt) (Max) 10mA
Current - Hold (Ih) (Max) 10mA
Configuration Single
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting Through Hole
Case / Package TO-202
Win Source Part Number 116489-Z0409MF 1AA2
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian Z0409MF 1AA2 CAD Model

Description

The Z0409MF 1AA2 is a high-performance Triac manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is designed to control AC loads for a wide range of applications, providing efficient and reliable operation. With its compact design and robust performance, the Z0409MF 1AA2 is an excellent choice for designers looking for a versatile AC power control solution.

Key Features

  • Current Rating: The device can handle a maximum RMS current of 4A, making it suitable for moderate power applications.
  • Repetitive Peak Off-State Voltage: With a repetitive peak off-state voltage (VDRM/VRRM) of 600V, it provides a high voltage capability suitable for many AC line applications.
  • Gate Trigger Voltage: A low gate trigger voltage (VGT) ensures easy triggering and efficient operation.
  • Surge Current: It offers a high surge current capability, essential for handling high inrush currents in applications such as motor starting.
  • Package: Housed in a TO-202-3 package, this Triac offers a compact footprint and is easy to integrate into various designs.

Applications

The Z0409MF 1AA2 is ideal for a diverse range of applications that require precise control of AC power. These include:

  • Home appliances such as electric heaters, kitchen aids, and lighting systems
  • Industrial tools and automation systems
  • Motor control circuits for fans, blowers, and pumps
  • AC phase control operations

Quality and Reliability

STMicroelectronics is known for its commitment to quality and the Z0409MF 1AA2 is no exception. It is designed to meet stringent industry standards, ensuring long-term reliability and performance. The device also provides built-in protection features, enhancing the safety and durability of the applications it is used in.

Environmental Compliance

The Z0409MF 1AA2 adheres to environmental standards and is compliant with RoHS and other regulations, reflecting STMicroelectronics' dedication to environmental sustainability.

With its combination of power handling, high voltage capability, and ease of use, the Z0409MF 1AA2 from STMicroelectronics stands out as a top choice for designers and engineers looking for a reliable Triac for their AC power control needs.
