Products specifications

Terminal Type Circular
Stud/Tab Size 10 Stud
Thickness 0.057" (1.45mm)
Width - Outer Edges 0.406" (10.31mm)
Length - Overall 1.181" (30.00mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp
Wire Gauge 6 AWG
Insulation Non-Insulated
Features Brazed Seam, Serrated Termination
Contact Material Copper
Contact Finish Tin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1635987-52197
Ultra Librarian 3D Model Ultra Librarian 52197 CAD Model
