Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Bits 12
Sampling Rate 50k
Number of Inputs 8
Input Type Differential, Single Ended
Data Interface I2C
Configuration MUX-S/H-ADC
Number of A/D Converters 1
Reference Type External, Internal
Analog Supply Voltage 2.7 V to 3.6 V, 5V
Digital Supply Voltage 2.7 V to 3.6 V, 5V
Temperature Range - Operating -40°C to 85°C
Case / Package 16-TSSOP
Win Source Part Number 087644-ADS7828E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management
Family Name ADS7828
Introduction Date January 01, 1995
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian ADS7828E CAD Model

Description

ADS7828E

The ADS7828E is a compact and reliable ADC, well-suited for precision applications requiring multiple channel input. It offers an optimal balance of performance, power efficiency, and ease of use.

Features and Benefits:

  • Multiplexed Input: Eight input channels allow for simultaneous monitoring of multiple signals.
  • Power Efficiency: Designed to minimize power usage, ideal for battery-operated applications.
  • Easy Integration: Simple interface for seamless integration with most controllers and microprocessors.
  • Compact Design: Small footprint facilitates incorporation into space-limited applications.

Applications:

  • Environmental Monitoring Systems
  • Medical Instrumentation
  • Data Acquisition Systems
  • Multisensor Fusion
