CD4060BE Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Logic Type Binary Counter
Direction Up
Number of Elements 1
Number of Bits per Element 14
Reset Asynchronous
Count Rate 12MHz
Trigger Type Negative Edge
Supply Voltage - Operating 3 V to 18 V
Temperature Range - Operating -55°C to 125°C
Mounting Through Hole
Case / Package 16-PDIP
Win Source Part Number 006189-CD4060BE
Family Name CD4060
Introduction Date January 01, 2002
ECCN EAR99
Country of Origin Malaysia\Mexico
Halogen Free Not Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Clock & Timing
Ultra Librarian 3D Model Ultra Librarian CD4060BE CAD Model

Description

CD4060BE

The CD4060BE binary counter/divider and oscillator is designed to facilitate the building of complex timing circuits with ease, offering a robust solution for demanding electronic projects.

  • Applications:
    • Sequential timing applications
    • Electronic control devices
    • Signal frequency dividing
    • Delay generators
  • Features and Benefits:
    • Versatile oscillator and counter functionality
    • CMOS technology for power efficiency
    • Enhanced noise tolerance for dependable operation
    • No need for external resistor-capacitor (RC) for oscillator setup
  • Additional Details:
    • DIP package supports easy prototyping
    • Wide operational voltage range
    • Usable in extreme temperature conditions (-55°C to +125°C)
