Products specifications

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 5 Weeks
Features 2/2 Transceiver Full RS232 16-TSSOP
Manufacturer Texas Instruments
Package Tube
Operating Temperature Range -40°C ~ 85°C
Mounting Surface Mount
Package 16-TSSOP (0.173", 4.40mm Width)
Case / Package 16-TSSOP
Family Name MAX232
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 296-33362-5, MAX232EIPW-ND, MAX232EIPWG4, MAX232EIPWG4-ND
Quantity per package 90
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 881356-MAX232EIPW
Ultra Librarian 3D Model Ultra Librarian MAX232EIPW CAD Model

Description

The MAX232EIPW is a versatile integrated circuit from Texas Instruments designed to facilitate serial communication in electronic devices. This chip is part of the MAX232 series, which are dual driver/receiver devices that include a capacitive voltage generator to supply TIA/EIA-232-F voltage levels from a single 5V supply.

Key Features

  • Interface Type: RS-232
  • Number of Drivers/Receivers: 2/2
  • Supply Voltage: 5V
  • Operating Temperature Range: 0°C to 70°C
  • Mounting Type: Through Hole
  • Package / Case: 16-PDIP (0.300", 7.62mm)
  • ESD Protection: Yes

The MAX232EIPW features two drivers and two receivers, making it suitable for the serial transmission of data between a microcontroller and other serial devices, such as computers, modems, and other peripherals. The chip converts signals from an RS-232 serial port to signals suitable for use in TTL-compatible digital logic circuits, thus bridging the gap between these two different signal standards.

This device is designed to be robust, offering electrostatic discharge (ESD) protection exceeding 2000V on the RS-232 transceiver pins, which helps prevent damage to the electronic components during handling or operation. The MAX232EIPW operates at a standard 5V power supply, and its 16-pin PDIP (Plastic Dual In-line Package) makes it easy to integrate into a wide range of electronic projects.

With its reliable performance and Texas Instruments' reputation for high-quality electronic components, the MAX232EIPW is an excellent choice for engineers and designers looking to implement RS-232 communications in their projects. Its ease of use, combined with its protective features, ensures that this integrated circuit remains a popular choice for serial communication applications.
