Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 081162-MAX3232ECDBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3232ECDBR CAD Model

Description

The MAX3232ECDBR is a highly sophisticated and advanced product manufactured by Texas Instruments, a renowned name in the world of electronics and semiconductors.

  • Type: 2/2 transceiver (two drivers and two receivers)
  • Operating Voltage: 3.0V to 5.5V
  • Feature: Low power consumption
  • Data Signaling Rate: 120Kbps
  • ESD Protection: Up to ±15kV IEC61000-4-2 Air-Gap Discharge, ±8kV IEC61000-4-2 Contact Discharge, and ±15kV Human-Body Model
  • Application: Cellular phones, laptops, PDAs, and other portable equipment
  • Feature: Automatic power-down
  • Package: 16-pin SSOP (DB)
  • Temperature Range: -40°C to 85°C
