PCA9306DCTR Texas Instruments
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Translator Type Voltage Level
Channel Type Bidirectional
Number of Circuits 1
Channels per Circuit 2
Voltage - VCCA 1.2V to 3.3V
Voltage - VCCB 1.8V to 5.5V
Output Type Open Drain, Push-Pull
Temperature Range - Operating -40°C to 85°C (TA)
Features Auto-Direction Sensing
Mounting SMD (SMT)
Case / Package SM8
Win Source Part Number 026440-PCA9306DCTR
Family Name PCA9306
Introduction Date June 06, 2005
ECCN EAR99
Country of Origin Japan, Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing, Communications & Networking, Computers & Computer Peripherals, Industrial, Automation & Process Control
Ultra Librarian 3D Model Ultra Librarian PCA9306DCTR CAD Model

Description

The PCA9306DCTR is a highly advanced, innovative product from the reputable company, Texas Instruments.

  • Product: PCA9306DCTR
  • Manufacturer: Texas Instruments
  • Description: Dual bidirectional I2C and SMBus voltage-level translator with an enable (EN) input
  • VREF1 Operation: 1.2-V to 3.3-V
  • VREF2 Operation: 1.8-V to 5.5-V
  • Applications: Advanced computing, networking, and telecommunications systems, server and PC platforms
  • VREF1 Low Voltage: 1.5-V
  • Design: Open-drain
  • Stand-by Current: Low
  • Integration: High level of integration and compatibility with other Texas Instruments products
  • Package: Small 8-pin DCT package
  • Operation Temperature: -40°C to +85°C
