Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series PTH05050W
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 0.8 ~ 3.6 V
Current - Output (Max) 6A
Applications ITE (Commercial)
Features Remote On/Off, OCP, UVLO
Mounting Style SMD/SMT
Package 6-SMD Module
Size / Dimension 0.87" L x 0.50" W x 0.36" H (22.1mm x 12.7mm x 9.1mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 95%
Power (Watts) - Max 21.6W
Win Source Part Number 142814-PTH05050WAZ
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PTH05050WAZ CAD Model

Description

The PTH05050WAZ is a high-performance, 6A rated, non-isolated power module from Texas Instruments.

  • Input Voltage Range: 5V to 14V
  • Output Voltage: Adjustable from 0.8V to 3.6V
  • Efficiency: Up to 96%
  • On/Off Inhibit Control: Onboard
  • Under-Voltage Lockout (UVLO): Yes
  • Operating Temperature Range: -40°C to 85°C
