PTN78000AAZ

Name: PTN78000AAZ
Brand: Texas Instruments
SKU: 284011
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PTN78000AAZ
Manufacturer	Texas Instruments
Catalog	Power Supplies Board Mount DCDC Converters
Description	REG SW -15 TO -3.3V 1.5A SMD
Datasheet	PTN78000AAZ Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount
Family	DC DC Converters
Manufacturer	Texas Instruments
Series	PTN78000A
Packaging	Tray
Type	Non-Isolated PoL Module
Number of Outputs	1
Voltage - Input (Min)	7V
Voltage - Input (Max)	28.7V
Voltage - Output 1	-15 ~ -3 V
Current - Output (Max)	1.5A
Applications	ITE (Commercial)
Features	OTP, UVLO
Mounting Style	SMD/SMT
Package	5-SMD Module
Size / Dimension	0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm)
Operating Temperature Range	-40°C ~ 85°C
Efficiency	84%
Power (Watts) - Max	9W
Win Source Part Number	004475-PTN78000AAZ
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian PTN78000AAZ CAD Model

Description

The PTN78000AAZ is a high-performance, integrated circuit (IC) power module from Texas Instruments, a leading global semiconductor manufacturer.

Input Voltage Range: 36V to 75V
Output Voltage Range: Adjustable output voltage range of 1.5V to 5.5V
Output Current: Up to 2.25A
Protection: Over-temperature and over-current protection mechanisms
Control: On/off inhibit control and output voltage adjustment
Package: 15-pin, low-profile surface-mount package
Compliance: RoHS directive
