SN65HVD05DR Real Image SN65HVD05DR real image5670
Same model may have multiple batches, images only for reference.
SN65HVD05DR Real Image SN65HVD05DR real image5670
SN65HVD05DR Real Image SN65HVD05DR real image5670
Same model may have multiple batches, images only for reference.

SN65HVD05DR

Part No SN65HVD05DR
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC RS485 TXRX 40MBPS 8-SOIC
Datasheet
SN65HVD05DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 35mV
Data Rate 40Mbps
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 029511-SN65HVD05DR
Family Name SN65HVD05
Introduction Date July 01, 2006
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN65HVD05DR CAD Model

Description

The SN65HVD05DR is a premium product from Texas Instruments, a renowned global semiconductor company that designs, manufactures, and sells analog and embedded processing chips.

  • Product Category: Differential Line Transceiver
  • RS-485 Family: Yes
  • High-Speed Data Transmission: Yes
  • Bidirectional Communication: Yes
  • Supply Voltage Range: 4.5V to 5.5V
  • Data Rate: Up to 50 Mbps
  • Electrostatic Discharge (ESD) Protection: Up to ±15kV
  • Thermal Shutdown Protection: Yes
  • Package: 8-pin SOIC
  • RoHS Compliant: Yes
