The TLC2272CD from Texas Instruments is a high-precision operational amplifier that has set the standard for versatility and performance in a wide range of analog circuits. This device is part of the LinCMOS™ family, which means it is fabricated using a silicon-gate CMOS process that offers the inherent benefits of low bias current, high input impedance, and low power consumption while maintaining the speed and driving capability of a traditional bipolar op-amp.

Key Features

• Low Noise: With a low noise floor, the TLC2272CD is an excellent choice for audio applications and signal conditioning in sensitive measurement equipment.
• High Output Drive: Capable of delivering a high output current, this op-amp can drive capacitive loads and power-hungry devices with ease.
• Wide Supply Range: The device operates from a single supply range of 4.4 V to 16 V or from a dual supply of ±2.2 V to ±8 V, making it adaptable to various circuit configurations.
• Rail-to-Rail Output: The output can swing very close to the supply rails, maximizing the dynamic range in battery-powered and single-supply applications.
• Low Power Consumption: The TLC2272CD is designed for low power consumption, which is ideal for battery-operated and portable devices.

Applications

The TLC2272CD is suited for a multitude of applications, including but not limited to:

• Active filters
• Signal conditioning
• Audio electronics
• Data acquisition systems
• Instrumentation
• Medical equipment

Package and Quality

The operational amplifier is available in an 8-pin SOIC package, which is compact and suitable for surface-mount technology. Texas Instruments is known for its commitment to quality, and the TLC2272CD is no exception, ensuring reliable performance in both commercial and industrial applications.
