Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Tube
Type Transceiver
Number of Drivers/Receivers 2/2
Operating Supply Voltage 1.71 V ~ 1.89 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 144-BBGA, FCBGA
Manufacturer Package 144-FCBGA (13x13)
Win Source Part Number 1269635-TLK10022CTR
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name TLK10022
Introduction Date November 08, 2013
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TLK10022CTR CAD Model

Description

The TLK10022CTR is a versatile dual-channel multi-rate transceiver module from Texas Instruments, designed to provide high-speed serial data communication in a broad range of applications. This advanced IC (Integrated Circuit) is capable of supporting data rates from 1 Gbps up to 10 Gbps per channel, making it an ideal solution for applications that require fast and reliable data transfer.

Key Features

  • Dual-Channel Operation: The TLK10022CTR operates with two independent channels, allowing simultaneous bidirectional data transmission.
  • Multi-Rate Flexibility: This transceiver supports a wide range of data rates, accommodating various protocols and interface standards.
  • Programmable Equalization: Integrated programmable equalization helps to maintain signal integrity over long cable lengths or through challenging transmission media.
  • Low Power Consumption: Designed with power efficiency in mind, the TLK10022CTR minimizes power usage, which is critical for thermally sensitive applications.
  • Small Form Factor: The compact size of the TLK10022CTR makes it suitable for high-density board designs, conserving valuable PCB (Printed Circuit Board) space.

Applications

The TLK10022CTR is highly suited for a variety of applications, including but not limited to:

  • Data center and enterprise networking equipment such as switches and routers.
  • High-speed backplanes and point-to-point data links.
  • Telecommunication infrastructure like SONET/SDH, OTN (Optical Transport Network).
  • Video broadcasting and professional A/V (Audio/Video) equipment.
  • Industrial control systems and high-speed data acquisition.

Technical Specifications

The TLK10022CTR offers robust technical specifications that ensure its reliability and performance across different use cases:

  • Supply Voltage: Operates at a core voltage of 1.2V with I/O voltages of 1.5V or 1.8V.
  • Temperature Range: Industrial temperature range from -40°C to 85°C.
  • Package: Supplied in a compact 144-pin VQFN (Very Thin Quad Flat Non-leaded) package.
  • Reliability: Built to meet or exceed the rigorous standards set by Texas Instruments for durability and longevity.

With its combination of speed, versatility, and reliability, the TLK10022CTR from Texas Instruments is a top choice for designers looking to implement high-speed data transfer in their systems.
