Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type N-Channel MOSFET
Supply Voltage - Operating 4 V to 14 V
Logic Voltage - VIL, VIH 1V, 4V
Current - Peak Output (Source, Sink) 2A, 2A
Input Type Non-Inverting
Rise and Fall Time 14ns, 14ns
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 033783-TPS2829DBVR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TPS2829
Introduction Date July 01, 2004
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS2829DBVR CAD Model

Description

Overview of Texas Instruments TPS2829DBVR

The Texas Instruments TPS2829DBVR is a high-speed, single-channel MOSFET driver designed to deliver exceptional performance for a wide range of power management applications. This compact driver is housed in a SOT-23-6 package, making it an ideal choice for space-constrained environments where efficient power switching is critical.

Key Features

  • High-Speed Operation: The TPS2829DBVR offers fast switching speeds, which helps in reducing transition losses and improving overall efficiency in power circuits.
  • Peak Output Current: Capable of delivering peak output currents of up to 2A, this driver can effectively drive large capacitive loads with ease.
  • Wide Supply Voltage Range: It operates over a broad supply voltage range from 4.5V to 18V, making it versatile for various applications and compatible with a variety of control logic levels.
  • Low Propagation Delay: The device features a low propagation delay, ensuring precise control and faster response times in critical power management systems.
  • Dual Input Configuration: It supports both inverting and non-inverting inputs, providing design flexibility and allowing for easy integration into different circuit topologies.
  • Robust Protection Features: The TPS2829DBVR includes under-voltage lockout (UVLO) to ensure the driver operates only when the supply voltage is sufficient, thereby protecting the MOSFET and the driver itself from under-voltage conditions.

Applications

With its high-speed performance and robust design, the TPS2829DBVR is well-suited for a variety of applications, including:

  • DC/DC Converters
  • Motor Controllers
  • Power Supplies
  • Synchronous Rectifier Circuits
  • Switch Mode Power Supplies (SMPS)

Conclusion

The TPS2829DBVR from Texas Instruments is a highly efficient and reliable solution for driving power MOSFETs. Its high-speed operation, coupled with a range of protective features, makes it an excellent choice for designers looking to optimize their power management systems in both commercial and industrial settings. The compact SOT-23-6 package allows for its use in applications where board space is at a premium, without compromising on performance.
