Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type N-Channel MOSFET
Supply Voltage - Operating 4 V to 14 V
Logic Voltage - VIL, VIH 1V, 4V
Current - Peak Output (Source, Sink) 2A, 2A
Input Type Non-Inverting
Rise and Fall Time 14ns, 14ns
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 1111580-TPS2829DBVT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS2829DBVT CAD Model

Description

Overview of Texas Instruments TPS2829DBVT

The Texas Instruments TPS2829DBVT is a high-speed, single-channel MOSFET driver designed to drive a power MOSFET in switching applications. With its fast rise and fall times, the TPS2829DBVT is particularly well-suited for high-frequency power conversion systems, offering efficient operation and improved power density.

Key Features

  • High-Speed Operation: The device features fast rise and fall times, typically 6ns and 7ns respectively, enabling quick switching of the connected MOSFET and reducing switching losses.
  • High Peak Output Current: Capable of delivering a peak output current of up to 2A, the TPS2829DBVT can drive large capacitive loads, ensuring robust operation even in demanding applications.
  • Wide Supply Voltage Range: Operating from a supply voltage range of 4.5V to 18V, the driver is versatile and can be used in a variety of power systems.
  • Low Shutdown Current: The shutdown current is typically less than 1µA, which helps to minimize power consumption when the driver is not in active use.
  • Dual Input Logic: The driver accepts both inverting and non-inverting input signals, providing design flexibility and ease of integration into existing circuits.

Applications

The TPS2829DBVT is ideal for a range of applications, including:

  • DC/DC Converters
  • Motor Control Circuits
  • Power Supplies
  • Class-D Amplifiers
  • LED Lighting

Package and Quality

Encased in a compact SOT-23-5 package, the TPS2829DBVT occupies minimal board space, making it an excellent choice for space-constrained applications. Texas Instruments is known for its commitment to quality, and this driver is no exception, ensuring reliable performance and longevity.

Conclusion

With its high-speed operation, robust output drive capability, and flexible power supply requirements, the Texas Instruments TPS2829DBVT MOSFET driver is a powerful component for modern electronic systems requiring efficient power management. Its small footprint and comprehensive feature set make it an attractive solution for designers looking to enhance the performance of their power conversion and motor control applications.
