Products specifications

Manufacturer TM
Win Source Part Number 372123-TM1629BS
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TM1629BS CAD Model

Description

The TM1629BS is a specialized LED driver controller IC manufactured by TM. Similar to the TM1629, it is designed to control LED displays and often integrates keypad scanning functionality. This IC is commonly used in consumer electronics and various appliance applications to manage LED segment displays and to handle user input via a keypad interface.

Applications

  • Home Appliances (microwave ovens, air conditioners, washing machines, refrigerators)
  • Audio and Video Equipment (DVD players, stereos, set-top boxes, remote controls)
  • Instrumentation (digital meters, panel displays, test equipment)
  • Gaming Peripherals (keyboards, controllers)
  • Electronic Scales

Features

  • LED Display Driver: Capable of driving a specific number of LED segments and digits, commonly used with 7-segment or 16-segment displays.
  • Keypad Scanning: Integrated keypad scanning feature enables accepting user input directly through a connected keypad.
  • Serial Interface: Communicates with a microcontroller via a serial interface, which may include SPI or similar protocols.
  • Adjustable Brightness: Allows for brightness control of the LED display, providing customization options for different environments.
  • Power-Saving Mode: Includes a power-down or sleep mode designed to reduce power consumption when the display is inactive.
  • Various Display Modes: Supports different display configurations and modes.

Benefits

  • Simplified Design: By integrating LED driving and keypad scanning functions, the need for numerous external components is reduced.
  • Cost-Effective: The reduced component count and integrated features contribute to a lower overall system cost.
  • Reduced PCB Space: Integrating multiple functions into a single chip saves considerable space on the printed circuit board.
  • Easy Microcontroller Interface: The serial communication streamlines the connection and control from a microcontroller.
  • Customizable Display: Adjustable brightness levels and display modes enable adapting the display to various operating environments and user preferences.
  • Lower Power Consumption: The power-saving mode helps to extend battery life in portable applications.

Additional Details

The TM1629BS typically operates on a voltage range of 3V to 5V. It often utilizes a 2-wire or 3-wire serial interface for communication. The IC provides segment current control for driving LEDs. The datasheet specifies the exact number of digits and segments it can manage. It's important to consult the datasheet for detailed electrical characteristics, pinout configurations, and application guidelines to ensure correct implementation and prevent device damage. The operating temperature range should be carefully considered to ensure reliable operation under the intended environmental conditions.
