TLP290(GB-TP,SE

Name: TLP290(GB-TP,SE
Brand: Toshiba Semiconductor and Storage
SKU: 525881
Availability: InStock
Rating: 4.91 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP290(GB-TP,SE
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	Optocoupler AC-IN 1-CH Transistor DC-OUT 4-Pin SO T/R / OPTOISOLATOR 3.75KV TRANS 4-SO
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	3750Vrms
Minimum DC Current Transfer Ratio	100% @ 5mA
Maximum DC Current Transfer Ratio	600% @ 5mA
Switching Turn-On and Turn-Off Time	3μs, 3μs
Rise and Fall Time	2μs, 3μs
Input Type	AC, DC
Output Type	Transistor
Maximum Output Voltage	80V
Channel Output Current	50mA
Forward Voltage	1.25V
Continuous forward current- Max	50mA
Vce Saturation (Max)	300mV
Temperature Range - Operating	-55°C to 110°C
Mounting	SMD (SMT)
Case / Package	4-SO
Win Source Part Number	1108897-TLP290(GB-TP,SE
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	TLP290
ECCN	EAR99
Country of Origin	Thailand
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian TLP290(GB-TP,SE CAD Model

Alternative Products

Description

The TLP290 is a high-performance optocoupler manufactured by Toshiba Semiconductor and Storage.

Channel: Single
Input Signal: AC and DC
DC Current Transfer Ratio (Min): 100% @ 5mA
DC Current Transfer Ratio (Max): 600% @ 5mA
Isolation Voltage: 3750Vrms
Maximum Output Voltage: 80V
Vce Saturation: 300mV
Continuous Forward Current: 50mA
Switching Turn-On Time: 3μs
Switching Turn-Off Time: 3μs
Rise Time: 2μs
Fall Time: 3μs
Package: 4-SO
Operating Temperature: -55°C to 110°C
