AZ2150-1A-12DEF Real Image
Same model may have multiple batches, images only for reference.

AZ2150-1A-12DEF

Part No AZ2150-1A-12DEF
Manufacturer American Zettler, Inc.
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 40A 12V / General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Through Hole
Datasheet
AZ2150-1A-12DEF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Power Relays, Over 2 Amps
Mfr American Zettler, Inc.
Package Tray
Product Status Active
Mounting Type Through Hole
Coil Voltage 12VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 40 A
Switching Voltage 300VAC, 30VDC - Max
Coil Current 77.4 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Coil Insulation Class F
Must Operate Voltage 9 VDC
Must Release Voltage 1.2 VDC
Operate Time 12 ms
Release Time 5 ms
Temperature Range - Operating -55°C ~ 85°C
Contact Material Silver Cadmium Oxide (AgCdO)
Relay Type General Purpose
Coil Resistance 155 Ohms
Base Product Number AZ2150
Standard Package 40 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0050
Win Source Part Number 844844-AZ2150-1A-12DEF
Ultra Librarian 3D Model Ultra Librarian AZ2150-1A-12DEF CAD Model

Description

The 844844-AZ2150-1A-12DEF is a power relay designed for various applications in the electronics industry.

  • Series: General-purpose relay series
  • Contact Form: Single-pole, normally open (SPST-NO)
  • Contact Material: Silver cadmium oxide (AgCdO)
  • Contact Rating: 40A
  • Switching Voltage: 300VAC or 30VDC
  • Coil Voltage: 12VDC
  • Coil Resistance: 155 Ohms
  • Coil Current: 77.4mA
  • Operate Time: 12ms
  • Release Time: 5ms
  • Feature: Sealed Fully
  • Temperature Range: -55°C to 85°C
  • Mounting: Through Hole
  • Packaging: Tray
  • Pieces per Standard Package: 40
  • Manufacturer: American Zettler, Inc.
