SG16 Ametherm
Same model may have multiple batches, images only for reference.

SG16

Part No SG16
Manufacturer Ametherm
Catalog Inrush Current Limiters (ICL)
Description ICL 60 OHM 10% 1.5A 15.24MM
Datasheet
SG16 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Inrush Current Limiters (ICL)
Mfr Ametherm
Series SURGE-GARD™
Package Bulk
Product Status Active
R @ 25°C 60 Ohms
Tolerance ±10%
Current - Steady State Max 1.5 A
R @ Current 1 Ohms
Diameter 0.600" (15.24mm)
Lead Spacing 0.310" (7.87mm)
Approval Agency CSA, UR
Standard Package 500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
Win Source Part Number 665569-SG16
Ultra Librarian 3D Model Ultra Librarian SG16 CAD Model

Description

The 665569-SG16 is a circuit protection component from the SURGE-GARD™ series by Ametherm.

  • Series: SURGE-GARD™
  • Function: Inrush Current Limiter (ICL)
  • Tolerance: ±10%
  • Lead Spacing: 0.310" (7.87mm)
  • Diameter: 0.600" (15.24mm)
  • Steady State Maximum Current: 1.5 A
  • Resistance @ 25°C: 60 Ohms
  • R @ Current: 1 Ohm
  • Approvals: CSA and UR
  • Package: Bulk
  • Standard Package: 500 pcs
