ADP7104ACPZ-R7

Part No ADP7104ACPZ-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 0.5A 8LFCSP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Reel package
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage Input MAX 20V
Output Voltage 1.22V
Output Voltage MAX 19.45V
Voltage Dropout (Maximum) 0.55V @ 500mA
Output Current 500mA
Operating Supply Current 900μA ~ 1.6mA
PSRR 80dB ~ 50dB (10kHz ~ 100kHz)
Control Features Enable, Power Good, Under Voltage Lockout
Protection Features Over Temperature, Short Circuit
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package 8-WFDFN Exposed Pad, CSP
Manufacturer Package 8-LFCSP-WD (3x3)
Win Source Part Number 768052-ADP7104ACPZ-R7
Popularity Medium
Supply and Demand Status Limited
Family Name ADP7104
Introduction Date October 19, 2011
ECCN EAR99
Country of Origin Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian ADP7104ACPZ-R7 CAD Model

Description

ADP7104ACPZ-R7: Low Dropout Linear Regulator by Analog Devices Inc.

The ADP7104ACPZ-R7 is a high-performance, low dropout linear regulator (LDO) from the reputable manufacturer Analog Devices Inc. This component is designed to provide precision voltage regulation with a maximum current output of 500 mA, making it an ideal choice for sensitive applications that require a stable and clean power supply. The device operates over a wide input voltage range from 3.3V to 20V, offering flexibility for various power systems.

One of the standout features of the ADP7104ACPZ-R7 is its low dropout voltage, which ensures efficient operation even when the input voltage is very close to the output voltage. This characteristic is particularly beneficial in battery-operated devices, where maximizing the usage of available power is critical. The LDO also boasts excellent transient response, which helps maintain a stable output voltage despite rapid changes in load, further enhancing the reliability of the power supply in dynamic conditions.

The ADP7104ACPZ-R7 comes in a compact 8-lead LFCSP (Lead Frame Chip Scale Package) that is ideal for space-constrained applications. Its small footprint does not compromise its performance, as the device includes an array of protection features such as overcurrent protection, thermal overload protection, and reverse battery protection, safeguarding both the regulator and the downstream components from potential damage.

With a low quiescent current, the ADP7104ACPZ-R7 is also an excellent choice for power-sensitive designs, contributing to the overall energy efficiency of the system. The device is available with several fixed output voltage options or with an adjustable output voltage, providing designers with the flexibility to choose the configuration that best fits their specific requirements.

In summary, the ADP7104ACPZ-R7 from Analog Devices Inc. is a versatile and robust LDO that offers precision voltage regulation, low dropout performance, and a suite of protective features. Whether you're working on portable devices, data communication equipment, or any application that demands a high-quality power supply, this LDO is engineered to meet the stringent requirements of a wide array of industries and applications.
