ADUM1310ARWZ-RL - Digital Isolator from Analog Devices Inc.

The ADUM1310ARWZ-RL is a robust digital isolator designed and manufactured by Analog Devices Inc., a leader in high-performance semiconductors. This component utilizes Analog Devices' proprietary iCoupler® technology to facilitate signal transfer across a galvanic isolation barrier, ensuring that sensitive digital circuits are protected from high voltages and noise commonly found in industrial, medical, and other harsh environments.

Key Features:

• Isolation Technology: The device employs iCoupler® chip-scale transformer technology, providing 2.5kV RMS isolation for 1 minute per UL 1577.
• Channel Configuration: It features three independent isolation channels, two forward and one reverse, making it suitable for a variety of bidirectional communication protocols.
• Data Rate: Supports data rates up to 10 Mbps, ensuring high-speed data transfer with minimal signal distortion.
• Power Supply: The ADUM1310ARWZ-RL operates from a single 3.0 V to 5.5 V power supply, accommodating a wide range of applications.
• Temperature Range: Designed for operation over the industrial temperature range of -40°C to +105°C, making it reliable in extreme conditions.
• Package: Available in a 16-lead SOIC wide body package (package code "RWZ"), it is compact and suitable for space-constrained applications.
• Lead-Free and RoHS Compliant: This component adheres to environmental standards, being lead-free and compliant with the Restriction of Hazardous Substances (RoHS) directive.

Applications:

The ADUM1310ARWZ-RL is ideal for a range of applications that require reliable isolation, such as:

• Industrial automation and control systems
• Sensing and data acquisition systems
• Medical equipment with stringent safety requirements
• Isolated RS-232/RS-422/RS-485 interfaces
• Power supply control and monitoring

With its advanced isolation capabilities, high data rates, and robust performance, the ADUM1310ARWZ-RL from Analog Devices Inc. is an excellent choice for designers seeking to enhance the safety and integrity of their digital systems.
