AD9277BSVZ Octal Ultrasound Receiver from Analog Devices Inc.

The AD9277BSVZ is a high-performance, octal-channel ultrasound receiver designed by Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing (DSP) integrated circuits. This component is engineered to cater to the demanding needs of medical ultrasound applications, offering a combination of low noise, high integration, and exceptional image quality.

Key features of the AD9277BSVZ include eight channels of a low-noise preamplifier (LNA), a variable gain amplifier (VGA), an anti-aliasing filter (AAF), and a 14-bit, 10 MSPS to 50 MSPS analog-to-digital converter (ADC). The integration of these components into a single package allows for significant space savings on the ultrasound system's printed circuit board (PCB), leading to more compact and portable designs.

The LNA has a low input-referred noise density of just 0.75 nV/√Hz, which is critical for maintaining signal integrity and ensuring high-quality imaging. The VGA provides a continuous gain adjustment from 21 dB to 52 dB, allowing for fine-tuning of the signal amplitude to match the ADC's dynamic range. The AAF is a fifth-order Butterworth filter with a programmable cutoff frequency, ensuring that unwanted high-frequency signals are effectively attenuated to prevent aliasing artifacts in the digitized output.

Each channel of the AD9277BSVZ has a fully differential signal path, which enhances the common-mode rejection ratio (CMRR) and reduces system noise. The device also features a digital I/Q demodulator with programmable phase rotation, enabling efficient processing of RF signals. The AD9277BSVZ operates on a 1.8 V analog supply and a 1.8 V to 3.3 V digital supply, providing flexibility in system power design.

For ease of integration, the AD9277BSVZ is available in a compact 100-lead, 14 mm × 14 mm CSP-BGA package, suitable for space-constrained applications. Its robust design and advanced features make it an ideal choice for high-end portable and cart-based ultrasound systems, where performance and form factor are paramount.

With the AD9277BSVZ, Analog Devices Inc. continues to push the boundaries of ultrasound technology, enabling medical professionals to deliver better diagnostics and care to patients worldwide.
