AT86RF230-ZUR

Part No AT86RF230-ZUR
Manufacturer Atmel
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU 802.15.4 32-VFQFN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Microchip Technology
Packaging Reel - TR
Status Obsolete(EOL)
Type TxRx + MCU
RF Family/Standard 802.15.4, General ISM > 1GHz
Protocol 6LoWPAN, WirelessHART, Zigbee
Modulation O-QPSK
Frequency 2.4GHz
Data Rate (Max) 250kbps
Power - Output 3dBm
Sensitivity -101dBm
Memory Size 128B SRAM
Serial Interfaces SPI
Supply Voltage - Operating 1.8 V to 3.6 V
Current - Receiving 15.5mA
Current - Transmitting 9.5mA to 16.5mA
Temperature Range - Operating -40°C to 85°C
Dimension 32-VFQFN Exposed Pad
Win Source Part Number 144873-AT86RF230-ZUR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AT86RF230-ZUR CAD Model

Description

Description

The AT86RF230-ZUR is a robust variant of the AT86RF230, known for its reliability and efficiency in wireless transmission. Particularly suited for ultra-reliable real-time communication applications, it is optimized for dense wireless network topologies.

Applications

  • Real-time asset tracking
  • Healthcare monitoring systems
  • Autonomous robotics communication
  • Military-grade communication networks
  • Safety-critical system monitoring

Features and Benefits

  • High reliability for mission-critical applications
  • Enhanced interference resistance for data integrity
  • Low latency and high throughput communication
  • Extended operational lifespan
  • Compatibility with a broad range of antennas

Additional Information

The AT86RF230-ZUR is designed to maintain robust performance even in environments with high levels of RF noise, ensuring that data transmission is reliable and accurate. This makes it suitable for applications where performance cannot be compromised.
