VC14MA0160KBA Real Image
Same model may have multiple batches, images only for reference.

VC14MA0160KBA

Part No VC14MA0160KBA
Manufacturer AVX Corporation
Catalog TVS - Varistors, MOVs
Description VARISTOR 24.5V 800A 1812
Datasheet
VC14MA0160KBA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer AVX Corporation
Packaging Reel - TR
Status Active
Varistor Voltage (Min) 22.05V
Varistor Voltage (Typ) 24.5V
Varistor Voltage (Max) 26.95V
Current - Surge 800A
Energy 2.4J
Number of Circuits 1
Maximum AC Volts 14VAC
Maximum DC Volts 16VDC
Capacitance @ Frequency 5400pF @ 1kHz
Temperature Range - Operating -55°C to 125°C (TA)
Mounting Surface Mount, MLCV
Dimension 1812 (4532 Metric)
Win Source Part Number 117017-VC14MA0160KBA
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VC14MA0160KBA CAD Model

Description

The AVX Corporation 117017-VC14MA0160KBA is a high-quality surface-mount varistor that offers a reliable solution for circuit protection.

  • Manufacturer: AVX Corporation
  • Capacitance: 5400pF @ 1kHz
  • Varistor Voltage Range: 22.05V to 26.95V
  • Maximum Energy Rating: 2.4J
  • Mounting: MLCV
  • Operating Temperature: -55°C to 125°C (TA)
  • Dimension: 1812 (4532 Metric)
  • Popularity: Medium
  • Supply and Demand: Balance
