Same model may have multiple batches, images only for reference.

BWD2412

Get a Quote

Part No	BWD2412
Manufacturer	Bel Power Solutions
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-12V 3W
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Bel Power Solutions
Series	BWD (3W)
Package	Bulk
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	18V
Voltage - Input (Max)	36V
Voltage - Output 1	12V
Voltage - Output 2	-12V
Current - Output (Max)	125mA, 125mA
Power (Watts)	3 W
Voltage - Isolation	500 V
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-25°C ~ 85°C
Efficiency	79%
Mounting Type	Through Hole
Package / Case	24-DIP Module, 10 Leads
Size / Dimension	1.25" L x 0.80" W x 0.52" H (31.8mm x 20.3mm x 13.2mm)
Standard Package	2 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	573822-BWD2412
Ultra Librarian 3D Model	Ultra Librarian BWD2412 CAD Model

Alternative Products

Description

The BWD2412 is a high-quality DC-DC converter module from Bel Power Solutions designed for power supply applications in the commercial IT equipment industry.

Series: BWD (3W)
Type: Isolated Module
Outputs: Two Outputs
Output Voltage: 12V and -12V
Power Output: 3W
Input Voltage Range: 18V to 36V
Isolation: 500V
Protection: Short Circuit Protection (SCP)
Size: 1.25" L x 0.80" W x 0.52" H
Mounting: Through-Hole
Package: Bulk (2 pieces)
