Same model may have multiple batches, images only for reference.
SRP0320-R68K Real Image
Same model may have multiple batches, images only for reference.

SRP0320-R68K

Part No SRP0320-R68K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0320
Package Tape & Reel
Material - Core Metal
Inductance 680 nH
Tolerance ±10%
Current Rating (Amps) 7.4 A
Current - Saturation (Isat) 6.7A
Shielding Shielded
DC Resistance (DCR) 14.8mOhm Max
Q @ Freq 8 @ 25.2MHz
Frequency - Self Resonant 62MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.134" L x 0.122" W (3.40mm x 3.10mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP0302-R68KDKR,118-SRP0320-R68KTR,SRP0302-R68K,118-SRP0302-R68KTR,118-SRP0320-R68KDKR,118-SRP0320-R68KCT,118-SRP0302-R68KCT
Standard Package 2,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274237-SRP0320-R68K
Ultra Librarian 3D Model Ultra Librarian SRP0320-R68K CAD Model

Description

The SRP0320-R68K inductor is a shielded fixed inductor designed by Bourns Inc.

  • Inductance: 680 nH
  • Tolerance: ±10%
  • DC Resistance: 14.8mOhm Max
  • Current Rating: 7.4 A
  • Q @ Freq: 8 @ 25.2MHz
  • Frequency Self-Resonant: 62MHz
  • Dimension: 0.134" L x 0.122" W (3.40mm x 3.10mm)
  • Mounting Type: SMD (SMT) technology
  • Material - Core: Metal core
  • Package / Case: Nonstandard
  • Operating Temperature Range: -40°C ~ 125°C
  • ECCN: EAR99 compliant
