SRP3012C-2R2M Real Image
Same model may have multiple batches, images only for reference.

SRP3012C-2R2M

Part No SRP3012C-2R2M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP3012C-2R2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP3012C
Package Tape & Reel
Material - Core Metal
Inductance 2.2 µH
Tolerance ±20%
Current Rating (Amps) 2.7 A
Current - Saturation (Isat) 3.2A
Shielding Shielded
DC Resistance (DCR) 115mOhm Max
Q @ Freq 10 @ 100kHz
Frequency - Self Resonant 38MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max) 0.047" (1.20mm)
Other Names 118-SRP3012C-2R2MTR,118-SRP3012C-2R2MDKR,118-SRP3012C-2R2MCT
Standard Package 4,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273986-SRP3012C-2R2M
Ultra Librarian 3D Model Ultra Librarian SRP3012C-2R2M CAD Model

Description

The Bourns Inc. SRP3012C-2R2M is a fixed inductor from the SRP3012C series.

  • Mounting Type: Shielded SMD (SMT)
  • Tolerance: ±20%
  • Material Core: Metal
  • Q @ Freq: 10 @ 100kHz
  • Frequency Self-Resonant: 38MHz
  • DC Resistance (DCR): 115mOhm Max
  • Current Rating: 2.7A
  • Inductance Frequency: 100 kHz
  • ECCN: EAR99
  • REACH: Unaffected
