Products specifications

Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 5
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 1 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Friction Lock
Overall Contact Length 0.560" (14.22mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Gold
Contact Material Copper Alloy
Temperature Range - Operating 0°C ~ 70°C
Material Flammability Rating UL94 V-0
Insulation Color White
Current Rating (Amps) 1A
Package Bulk
Supply and Demand Status Normal
Win Source Part Number 1630192-14191
Ultra Librarian 3D Model Ultra Librarian 14191 CAD Model
