The RS3GBF is a surface mount rectifier diode manufactured by Chendahang Electronics Co., Ltd. It is designed for general-purpose rectification in various electronic applications, offering efficient and reliable performance.

Applications

• General rectification in power supplies
• Reverse polarity protection circuits
• Freewheeling diode in inductive load applications
• AC-to-DC power conversion

Features

• High surge current capability
• Low forward voltage drop
• Surface mount SMA package
• High reliability and stability

Benefits

• Improved circuit protection due to high surge current handling.
• Efficient operation, minimizing power loss, due to low forward voltage drop.
• Space-saving design with SMA surface mount package.
• Consistent performance and long operational life due to its high reliability.

Technical Specifications

• Repetitive Peak Reverse Voltage (VRRM): 400V
• Average Forward Current (IF(AV)): 3.0A
• Forward Voltage (VF): 1.3V (at 3.0A)
• Surge Current (IFSM): 80A
• Package: SMA

The RS3GBF's ability to withstand high surge currents protects the circuit from voltage spikes and transients. The low forward voltage drop contributes to energy efficiency by minimizing power dissipation during operation. Its SMA surface mount package is ideal for automated assembly, reducing manufacturing costs and improving overall production efficiency. This diode provides a dependable and efficient solution for rectification needs in a wide array of electronic devices.
