Same model may have multiple batches, images only for reference.
MGFS402412 Real Image
Same model may have multiple batches, images only for reference.

MGFS402412

Part No MGFS402412
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 12V 41W / Isolated Module DC DC Converter 1 Output 12V 3.4A 9V - 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Cosel USA, Inc.
Series MGFS (40W)
Package Tube
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 12V
Current - Output (Max) 3.4A
Power (Watts) 41 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 92%
Mounting Type Through Hole
Package / Case 6-DIP Module
Size / Dimension 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
Control Features Enable, Active Low
Approval Agency CE, cURus, DEMKO
Standard Package 1
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9580
California Prop 65 Warning Information
Win Source Part Number 1342748-MGFS402412
Ultra Librarian 3D Model Ultra Librarian MGFS402412 CAD Model

Description

The Cosel USA MGFS402412 is a 40W isolated module DC-DC converter that comes in a tube package.

  • Power: 40W
  • Package: Tube
  • Application: ITE (Commercial)
  • Standard Package: 1
  • Efficiency: 92%
  • Voltage Isolation: 1.5 kV
  • Output Type: Single
  • Maximum Current: 3.4A
  • Voltage Output: 12V
  • Control Features: Enable, Active Low
  • Operating Temperature: -40°C to 85°C (with derating)
  • Mounting Type: Through Hole
  • Package/Case: 6-DIP Module
  • Approval Agency Certifications: CE, cURus, and DEMKO
