DS04-254-2-02BK-SMT

Part No DS04-254-2-02BK-SMT
Manufacturer CUI Inc.
Catalog DIP Switches
Description DIP SWITCH, SPST, 2.54 PITCH, FL / Dip Switch SPST 2 Position Surface Mount Slide (Standard) Actuator 25mA 24VDC
Datasheet
DS04-254-2-02BK-SMT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - DIP Switches
Mfr CUI Devices
Series DS04-254-SMT
Package Tube
Circuit SPST
Number of Positions 2
Current Rating (Amps) 25mA
Voltage Rating 24VDC
Actuator Type Slide (Standard)
Actuator Level Flush, Recessed
Contact Material Copper Alloy
Contact Finish Gold
Height Above Board 0.167" (4.25mm)
Mounting Type Surface Mount
Termination Style Gull Wing
Pitch 0.100" (2.54mm) , Full
Washable No
Temperature Range - Operating -40°C ~ 85°C
Body Material Polybutylene Terephthalate (PBT)
Length 0.239" (6.08mm)
Electrical Life 2,000 Cycles
Base Product Number DS04-254
Standard Package 70
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Win Source Part Number 1337303-DS04-254-2-02BK-SMT
Ultra Librarian 3D Model Ultra Librarian DS04-254-2-02BK-SMT CAD Model

Description

The DS04-254-SMT is a SPST slide switch from CUI Devices, designed for use in electronic devices that require a simple on/off function.

  • Circuit: SPST
  • Termination Style: Gull Wing
  • Contact Finish: Gold
  • Actuator Material: Polybutylene Terephthalate (PBT)
  • Voltage Rating: 24VDC
  • Electrical Life: 2,000 Cycles
  • Washable: Yes
  • Actuator Level: Flush/Recessed
  • Mounting Type: Surface Mount
  • Operating Temperature: -40°C ~ 85°C
  • Packaging: Tube
  • Standard Package: 70
