PDSE1-S12-D5-M-TR Real Image
Same model may have multiple batches, images only for reference.

PDSE1-S12-D5-M-TR

Part No PDSE1-S12-D5-M-TR
Manufacturer CUI Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC-DC ISOLATED 1.5KV, 1 W, 10.8~ / Isolated Module DC DC Converter 2 Output 5V -5V 100mA, 100mA 10.8V - 13.2V Input
Datasheet
PDSE1-S12-D5-M-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Manufacturer CUI Inc.
Packaging Reel - TR
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 10.8V
Voltage - Input (Max) 13.2V
Voltage - Output 1 5V
Voltage - Output 2 -5V
Current - Output (Max) 100mA, 100mA
Power (Watts) 1 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Temperature Range - Operating -40°C ~ 105°C (With Derating)
Efficiency 82%
Mounting Surface Mount
Case / Package 10-SMD Module, 6 Leads
Size / Dimension 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm)
Approval Agency CE, cURus
Standard Number 62368-1
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Other Part Number 102-PDSE1-S12-D5-M-TRDKR,102-PDSE1-S12-D5-M-TR,102-PDSE1-S12-D5-M-TRCT
Standard Package 500
Win Source Part Number 1335292-PDSE1-S12-D5-M-TR
Ultra Librarian 3D Model Ultra Librarian PDSE1-S12-D5-M-TR CAD Model

Description

The CUI Inc. 1335292-PDSE1-S12-D5-M-TR is a surface mount isolated module DC-DC converter, designed for ITE (Commercial) applications.

  • Power Output: 1 W
  • Efficiency: 82%
  • Voltage Input Range: 10.8V to 13.2V
  • Output Voltages: 5V and -5V
  • Maximum Output Current: 100mA for each output
  • Case/Package: 10-SMD module with 6 leads
  • Voltage Isolation: 1.5 kV
  • Operating Temperature: -40°C to 105°C (with derating)
  • RoHS Compliant: RoHS compliant
  • Approvals: CE and cURus approved
