C4D1006N-A Electroswitch – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

C4D1006N-A

Part No C4D1006N-A
Manufacturer Electroswitch
Catalog Rotary Switches
Description SWITCH ROTARY 2-6POS 300MA 125V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Positions 2 ~ 6
Index Stops Adjustable
Number of Decks 5
Number of Poles per Deck 2
Circuit per Deck DP6T
Contact Timing Non-Shorting (BBM)
Current Rating (Amps) 300mA (AC), 500mA (DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 28 V
Actuator Type Flatted (6.35mm Dia)
Actuator Length 12.70mm
Angle of Throw 30°
Contact Material Brass
Contact Finish Silver
Mounting Type Panel Mount
Termination Style Solder Lug
Depth Behind Panel 48.97mm
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1559468-C4D1006N-A
Ultra Librarian 3D Model Ultra Librarian C4D1006N-A CAD Model
