B82790S0513N201 Real Image B82790S0513N201 real image15179 B82790S0513N201 Real Image1 B82790S0513N201 Real Image2 B82790S0513N201 Real Image3
Same model may have multiple batches, images only for reference.
B82790S0513N201 Real Image B82790S0513N201 real image15179 B82790S0513N201 Real Image1 B82790S0513N201 Real Image2 B82790S0513N201 Real Image3
B82790S0513N201 Real Image B82790S0513N201 real image15179 B82790S0513N201 Real Image1 B82790S0513N201 Real Image2 B82790S0513N201 Real Image3
Same model may have multiple batches, images only for reference.

B82790S0513N201

Part No B82790S0513N201
Manufacturer EPCOS (TDK)
Catalog Common Mode Chokes
Description CMC 51UH 500MA 2LN SMD AEC-Q200
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer EPCOS (TDK)
Packaging Reel - TR
Status Active
Filter Type Signal Line
Number of Lines 2
Inductance @ Frequency 51μH @ 100kHz
Current Rating (Max) 500mA
DC Resistance (DCR) (Max) 140 mOhm (Typ)
Voltage Rating - DC 80V
Voltage Rating - AC 42V
Temperature Range - Operating -40°C to 125°C
Ratings AEC-Q200
Mounting SMD (SMT)
Height (Max) 0.205" (5.20mm)
Dimension Horizontal, 4 Gull Wing
Win Source Part Number 1021783-B82790S0513N201
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial, Power Management, Consumer Electronics, Portable Devices, Automotive
Ultra Librarian 3D Model Ultra Librarian B82790S0513N201 CAD Model

Description

The EPCOS (TDK) B82790S0513N201 is an AEC-Q200 rated SMD filter for signal lines with a current rating of 500mA.

  • AEC-Q200 Rated: Yes
  • Filter Type: SMD for signal lines
  • Current Rating: 500mA
  • Voltage Rating: 42VAC and 80VDC
  • Inductance: 51μH @ 100kHz
  • DC Resistance: 140 mOhm
  • Operating Temperature Range: -40°C to 125°C
  • Height: 0.205"
  • Mounting: Horizontally with 4 gull wing pins
  • Applications: Industrial, power management, consumer electronics, portable devices, and automotive
