Products specifications Report Issue?

Manufacturer Eutech Microelectronics
Win Source Part Number 1172855-EUP6514DIR1
Manufacturer Homepage www.eutechmicro.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian EUP6514DIR1 CAD Model

Description

The EUP6514DIR1 is a high-efficiency, synchronous boost converter from Eutech Microelectronics. Though listed as END-OF-LIFE, it was designed for applications requiring a stable output voltage higher than the input voltage, such as LED backlighting and portable power devices.

Applications:

  • LED Backlighting: Driving LED backlights in LCD displays for smartphones, tablets, and laptops.
  • Portable Power Devices: Boosting voltage for portable power banks and USB power delivery applications.
  • Boost Regulators: Used as a general-purpose boost regulator in various electronic circuits.
  • Battery-Powered Equipment: Boosting battery voltage to a higher level required by certain components.
  • White LED Drivers: Powering white LEDs in lighting applications.

Features:

  • High Efficiency: Achieves high efficiency through synchronous rectification, minimizing power loss.
  • Wide Input Voltage Range: Operates with a wide input voltage range, accommodating various power sources.
  • Adjustable Output Voltage: Allows for flexible voltage regulation to meet specific application requirements.
  • Overvoltage Protection (OVP): Includes OVP to protect connected devices from excessive voltage.
  • Overcurrent Protection (OCP): Features OCP to limit the output current and prevent damage from short circuits.
  • Short-Circuit Protection (SCP): Provides SCP to safeguard the device and connected components.
  • Thermal Shutdown Protection (OTP): Integrates OTP to automatically shut down the device in case of overheating.
  • Low Shutdown Current: Low shutdown current minimizes power consumption when the device is disabled.

Benefits:

  • Extended Battery Life: High efficiency contributes to extended battery life in portable applications.
  • Stable Output Voltage: Provides a stable and regulated voltage, ensuring consistent performance of connected devices.
  • Protection Against Fault Conditions: OVP, OCP, SCP, and OTP features enhance the reliability and safety of the system.
  • Flexible Voltage Regulation: Adjustable output voltage allows for adaptation to different application requirements.
  • Compact Solution: Small package allows for integration in space-constrained applications.

Additional Details:

The EUP6514DIR1 uses a current-mode control architecture for stable operation and fast transient response. External components such as inductors, capacitors, and resistors are required to configure the boost converter for specific applications. As this part is END-OF-LIFE, it's advisable to check with Eutech or distributors for availability of datasheets and application notes. Consult the manufacturer's datasheet for detailed specifications, including input voltage range, output current capability, switching frequency, and operating temperature range.
