Same model may have multiple batches, images only for reference.
04J-AS-T01 Real Image
Same model may have multiple batches, images only for reference.

04J-AS-T01

Part No 04J-AS-T01
Manufacturer Grayhill Inc.
Catalog PMIC - Motor Drivers, Controllers
Description SWITCH NAVIGATION CASTLE 2A 115V  /  Navigation Switch, 2 - Axis Digital (Mechanical Switch) Output
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Navigation Switches, Joystick
Mfr Grayhill Inc.
Series 04J
Package Bulk
Type Navigation Switch, 2 - Axis
Actuator Type Castle
Switch Function 4-Way Directional, Center Select
Output Digital (Mechanical Switch)
Current Rating (Amps) 2A (AC/DC)
Voltage Rating - AC 115 V
Voltage Rating - DC 28 V
Contact Material Nickel
Contact Finish Gold
Mounting Type Panel Mount
Termination Style Solder Lug
Temperature Range - Operating -55°C ~ 85°C
Ingress Protection IP68 - Dust Tight, Waterproof
Mechanical Life 100,000 Cycles
Electrical Life 100,000 Cycles
Operating Force 454gf
Base Product Number 04J-AS
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Other Names 04J-AS-T01-ND,GH7875
Standard Package 1
Win Source Part Number 1046199-04J-AS-T01
Ultra Librarian 3D Model Ultra Librarian 04J-AS-T01 CAD Model

Description

The Grayhill Inc. 04J-AS-T01 navigation switch is a 2-axis switch that is used in various electronic applications.

  • Termination Style: Solder Lug
  • Contact Material: Nickel
  • Ingress Protection: IP68
  • Voltage Rating: 115V AC, 28V DC
  • Packaging: Bulk
  • Supply and Demand Status: Balanced
  • ECCN: EAR99
  • HTSUS: 8536.50.9065
  • Current Rating: 2A (AC/DC)
  • Temperature Range: -55°C to 85°C
  • Mechanical Life: 100,000 cycles
