Same model may have multiple batches, images only for reference.

IRF7342TRPBF

Name: IRF7342TRPBF
Brand: Infineon Technologies
SKU: 159895
Availability: InStock
Rating: 4.85 (982 reviews)

Get a Quote

Part No	IRF7342TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET 2P-CH 55V 3.4A 8-SOIC
Datasheet	IRF7342TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
FET Type	2 P-Channel (Dual)
FET Feature	Logic Level Gate
Drain-Source Breakdown Voltage	55V
Continuous Drain Current at 25°C	3.4A
Maximum Rds On at Id,Vgs	105 mOhm @ 3.4A, 10V
Gate-Source Threshold Voltage	1V @ 250μA
Max Gate Charge	38nC @ 10V
Max Input Capacitance	690pF @ 25V
Maximum Power Dissipation	2W
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Win Source Part Number	017512-IRF7342TRPBF
Family Name	IRF7342
Introduction Date	March 17, 1999
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian IRF7342TRPBF CAD Model

Description

The IRF7342TRPBF is a dual P-channel MOSFET transistor manufactured by Infineon Technologies.

Maximum Power Dissipation: 2W
Drain-Source Breakdown Voltage: 55V
Maximum Rds on at Id, Vgs: 105 mOhm @ 3.4A, 10V
Package: 8-SO
Gate-Source Threshold Voltage: 1V @ 250μA
Commonly Used: discrete semiconductor products
