IRLML2502TR

Name: IRLML2502TR
Brand: Infineon Technologies
SKU: 605894
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRLML2502TR
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	HEXFETPower MOSFET \| MOSFET N-CH 20V 4.2A SOT-23
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Cut Tape (CT)
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	20V
Id - Continuous Drain Current	4.2A
Drive Voltage (Max Rds On, Min Rds On)	2.7V, 4.5V
Rds On (Maximum) at Id, Vgs	45mOhm at 4.2A, 4.5V
Gate Source Voltage(th) (Maximum) at Id	1.2V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	12nC at 5V
Gate Source Voltage (Maximum)	±12V
Input Capacitance (Ciss) (Maximum) at Vds	740pF at 15V
Power Dissipation (Maximum)	1.25W
Temperature Range - Operating	-55°C ~ 150°C
Mounting Style	SMD
Supplier Device Package	Micro3/SOT-23
Manufacturer Package	TO-236-3, SC-59, SOT-23-3
Manufacturer Pack Quantity	1
MSL Level	1 (Unlimited)
Win Source Part Number	1188582-IRLML2502TR
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian IRLML2502TR CAD Model

Alternative Products

Description

The 1188582-IRLML2502TR from Infineon Technologies is a high-quality MOSFET transistor that is designed to deliver exceptional performance and reliability.

Maximum Power Dissipation: 1.25W
Drain-Source Breakdown Voltage: 20V
Transistor Polarity: N-channel
Supplier Device Package: Micro3/SOT-23
Drive Voltage: 2.7V for maximum Rds on and 4.5V for minimum Rds on
Operating Temperature: -55°C to 150°C
Manufacturer: Infineon Technologies
