Same model may have multiple batches, images only for reference.
LCB120 Real Image
Same model may have multiple batches, images only for reference.

LCB120

Part No LCB120
Manufacturer IXYS
Catalog Solid State Relays
Description SSR RELAY SPST-NC 170MA 0-250V / Solid State SPST-NC (1 Form B) 6-DIP (0.300", 7.62mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr IXYS
Series LCB, OptoMOS®
Package Tube
Product Status Active
Mounting Type Through Hole
Circuit SPST-NC (1 Form B)
Output Type AC, DC
Voltage - Input 1.2VDC
Voltage - Load 0 V ~ 250 V
Load Current 170 mA
On-State Resistance (Max) 20 Ohms
Termination Style PC Pin
Package / Case 6-DIP (0.300", 7.62mm)
Supplier Device Package 6-DIP
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0030
California Prop 65 Warning Information
Win Source Part Number 177166-LCB120
Ultra Librarian 3D Model Ultra Librarian LCB120 CAD Model

Description

The LCB120 is a solid-state relay from IXYS.

  • Manufacturer: IXYS
  • Series: LCB, OptoMOS™
  • Termination Style: PC Pin
  • Mounting: Through-Hole
  • Voltage Input: 1.2VDC
  • Output Types: AC and DC
  • Circuit Configuration: SPST-NC (1 Form B)
  • On-State Resistance: 20 Ohms
  • Load Current Capacity: 170mA
  • Load Voltage Range: 0V to 250V
  • Package: 6-DIP
