8223 Real Image
Same model may have multiple batches, images only for reference.

8223

Part No 8223
Manufacturer Keystone Electronics
Catalog Terminals—Spade Connectors
Description MAGNET 0.980"D X 0.310"THICK RND
Datasheet
8223 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Magnets - Multi Purpose Magnets
Mfr Radial Magnets, Inc.
Package Bulk
Product Status Active
Shape Round
Magnetization Axial, Pot
Material Neodymium Iron Boron (NdFeB)
Finish NiCuNi
Grade N35
Size 0.980" Dia x 0.310" H (25.0mm x 8.00mm)
Temperature Range - Operating 80°C (TA)
Standard Package 100 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8505.11.0070
Win Source Part Number 850523-8223
Ultra Librarian 3D Model Ultra Librarian 8223 CAD Model

Description

The 850523-8223 Multi Purpose Magnet is a versatile sensor and transducer component used in various applications. Manufactured by Radial Magnets, Inc., this magnet is of high quality and reliability.

  • Material: Neodymium Iron Boron (NdFeB)
  • Shape: Round
  • Diameter: 0.980"
  • Height: 0.310"
  • Finish: NiCuNi
  • Operating Temperature: Up to 80°C
  • Magnetization: Axial and Pot
