Products specifications Report Issue?

Reference Date Code 0524+
Reference case SOP-8
Manufacturer Linear Technology
Manufacturer Homepage www.linear.com
RoHS State Request Verification
Win Source Part Number 754397-LT1641-2CS8
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT1641-2CS8 CAD Model

Description

Product Overview: LT1641-2CS8

The LT1641-2CS8 is a high-performance, positive high voltage hot swap controller designed by Linear Technology, now part of Analog Devices, to allow safe board insertion and removal from a live backplane. This integrated circuit is housed in an 8-lead SO package, making it compact and suitable for space-constrained applications.

Key Features

  • Voltage Range: The device operates over a wide voltage range, accommodating systems with supply voltages from 10.8V to 80V, making it versatile for various applications.
  • Electronic Circuit Breaker: It features an adjustable electronic circuit breaker, providing precise control over the maximum amount of power delivered to the load, enhancing system protection against overcurrent conditions.
  • Under-Voltage Lockout (UVLO): The LT1641-2CS8 includes UVLO with hysteresis to ensure that the device operates only when the supply voltage is within an acceptable range, protecting both the load and the controller.
  • Gate Drive for External N-Channel MOSFET: The controller drives an external N-Channel MOSFET, allowing it to handle various load currents and power levels tailored to specific applications.

Applications

The LT1641-2CS8 is ideal for a range of applications, including:

  • Hot Swap Systems
  • High Availability Servers
  • Redundant Power Supplies
  • Industrial Systems
  • Telecommunications Equipment

Design Advantages

With its robust feature set, the LT1641-2CS8 provides several design advantages:

  • Flexibility: The adjustable current limit allows designers to tailor the hot swap controller to their specific needs, providing flexibility across different board designs and systems.
  • Protection: The combination of features like the electronic circuit breaker and UVLO ensures comprehensive protection for both the electronic system and the hot swap controller itself.
  • Efficiency: By using an external N-Channel MOSFET, the LT1641-2CS8 offers efficient power management, which can be critical in systems where thermal performance and power dissipation are concerns.

Overall, the LT1641-2CS8 from Linear Technology is a reliable and efficient solution for managing hot swap events and protecting high voltage systems against a variety of electrical hazards.
