Products specifications

Reference Date Code 0306+
Reference case SOP-8
Manufacturer Linear Technology
Manufacturer Homepage www.linear.com
RoHS State Request Verification
Win Source Part Number 710884-LT1641CS8#TR
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT1641CS8#TR CAD Model

Description

The LT1641CS8#TR, from Linear Technology, is a high-performance, positive high voltage hot swap controller that allows a board to be safely inserted and removed from a live backplane. This integrated circuit is designed to control the gate voltage of an external N-channel MOSFET to gently power up capacitors, avoiding sparks, connector damage, and system glitches.

Key Features:

  • Voltage Range: The device operates over a wide voltage range, accommodating systems from 10.8V to 80V, making it ideal for a variety of applications including telecom and industrial systems.
  • Programmable Circuit Breaker: The LT1641CS8#TR features a programmable circuit breaker function, which provides precise control over the current limit threshold and helps protect both the power source and the load during fault conditions.
  • Automatic Retry or Latch Off: Upon detecting an overcurrent condition, the device can be configured for automatic retry or latch off, giving system designers flexibility in managing fault conditions.
  • Gate Control: The controller offers soft-start capability by controlling the gate of an external MOSFET, thereby limiting inrush current during start-up.
  • Under Voltage Lockout: It includes an under voltage lockout feature that ensures the controller remains off if the supply voltage is too low, thus safeguarding the system.
  • Compact Package: The device comes in a compact 8-lead SOIC package, which is suitable for space-constrained applications.

Applications:

  • Hot swap applications in servers and network switches
  • Industrial systems
  • Telecommunications equipment
  • Power distribution systems

The LT1641CS8#TR is designed for ease of use and reliability, featuring overcurrent protection, power good output, and a wide operating temperature range. With its robust feature set and Linear Technology's reputation for high-quality power management solutions, this hot swap controller is an excellent choice for engineers looking to improve the safety and reliability of their system power supplies.
